Gmsh

A three-dimensional finite element mesh generator with built-in pre- and post-processing facilities

Christophe Geuzaine and Jean-François Remacle

Download | Documentation | Licensing | Screenshots | Links | References |

Gmsh is an open source 3D finite element mesh generator with a built-in CAD engine and post-processor. Its design goal is to provide a fast, light and user-friendly meshing tool with parametric input and advanced visualization capabilities. Gmsh is built around four modules: geometry, mesh, solver and post-processing. The specification of any input to these modules is done either interactively using the graphical user interface, in ASCII text files using Gmsh's own scripting language (.geo files), or using the C++, C, Python or Julia Application Programming Interface (API).

See this general presentation for a high-level overview of Gmsh and recent developments, the screencasts for a quick tour of Gmsh's graphical user interface, and the reference manual for a more thorough overview of Gmsh's capabilities, some frequently asked questions and the documentation of the C++, C, Python and Julia API.

The source code repository contains many examples written using both the built-in script language and the API (see e.g. the tutorials and the additional examples).

Download

Gmsh is distributed under the terms of the GNU General Public License (GPL):

• Current stable release (version 4.10.5, 1 July 2022):

  • Download Gmsh for Windows, Linux or macOS (x86) ^*
  • Download the source code
  • Download the Software Development Kit (SDK) for Windows, Linux or macOS (x86) ^*
  • Download both Gmsh and the SDK with pip: 'pip install --upgrade gmsh'

  Make sure to read the tutorials before sending questions or bug reports.

• Development version:
  • Download the latest automatic Gmsh snapshot for Windows, Linux, macOS (x86) or macOS (arm) ^*
  • Download the latest automatic source code snapshot
  • Download the latest automatic SDK snapshot for Windows, Linux, macOS (x86) or macOS (arm) ^*
  • Access the Git repository: 'git clone https://gitlab.onelab.info/gmsh/gmsh.git'
  • Download the latest automatic snapshot of both Gmsh and the SDK with pip: 'pip install -i https://gmsh.info/python-packages-dev --force-reinstall --no-cache-dir gmsh' (on Linux systems without X windows, use python-packages-dev-nox instead of python-packages-dev)

• All versions: binaries and sources

If you use Gmsh please cite the following reference in your work (books, articles, reports, etc.): C. Geuzaine and J.-F. Remacle. Gmsh: a three-dimensional finite element mesh generator with built-in pre- and post-processing facilities. International Journal for Numerical Methods in Engineering 79(11), pp. 1309-1331, 2009. You can also cite additional references for specific features and algorithms.

Documentation

• General presentation with high-level overview of Gmsh and recent developments
• Gmsh reference manual (stable release) (also available in PDF and in plain text)
• Gmsh reference manual (development version) (also available in PDF and in plain text)
• Screencasts showing how to use the graphical user interface
• Gitlab development site with a wiki, time line of changes and the bug tracking database
• Changelog

Please report all issues on https://gitlab.onelab.info/gmsh/gmsh/issues.

Licensing

Gmsh is copyright (C) 1997-2022 by C. Geuzaine and J.-F. Remacle (see the CREDITS file for more information) and is distributed under the terms of the GNU General Public License (GPL) (version 2 or later, with an exception to allow for easier linking with external libraries).

In short, this means that everyone is free to use Gmsh and to redistribute it on a free basis. Gmsh is not in the public domain; it is copyrighted and there are restrictions on its distribution (see the license and the related frequently asked questions). For example, you cannot integrate this version of Gmsh (in full or in parts) in any closed-source software you plan to distribute (commercially or not). If you want to integrate parts of Gmsh into a closed-source software, or want to sell a modified closed-source version of Gmsh, you will need to obtain a commercial license: please contact us for details.

Screenshots

These are two screenshots of the Gmsh user interface, with either the light or dark user interface theme. See the ONELAB web site for more.

Links

• Gmsh uses OpenCascade for constructive geometry features, and interfaces the optional external mesh and mesh adaptation librairies Netgen and Mmg3d.
• Gmsh's cross-platform graphical user interface is based on FLTK and OpenGL.
• Gmsh's high quality vector PostScript, PDF and SVG output is produced by GL2PS.
• Gmsh implements a ONELAB server to drive external solvers such as the open source finite element solver GetDP. Gmsh and GetDP are bundled in the ONELAB app for iPhone, iPad and Android devices.
